Built for Entertainment
Motion, Lighting, Audio & More
Enterprise class integrated controls
Weigl devices can operate stand-alone or can connect with applications running on third-party devices. They can be programmed to receive input from a variety of sensors and can provide control for lights, motors, and other actuators.
Our flexible platform operates with a variety of software applications, and our protocol is continually published for custom development. From lighting to motion control and beyond, Weigl provides enterprise class control for themed entertainment.
ProCommander® X-Series
Next Generation Show Controllers
ProCommander® X Series provides advanced networking, polyphony, digital motor control and more, utilizing familiar Weigl timelines and our continually evolving WEM Script™ scripting language. Mix and match your favorite Pro I/O™ modules, integrate external lighting or media interfaces and build your show in Conductor or Showforge® in real-time. Our most powerful controllers yet, these ProCommanders provide what’s needed to accommodate today’s most interactive project spaces.
FEATURES:
- Up to 16 digital outputs
- Up to 8 polyphonic audio channels
- SMPTE In/Out
- Full color touchscreen (HX/VX only).
- 16 inputs, multiple configurations
- 3 serial ports (1 RS-485)
- 512 channels of local DMX in/out
- Up to 16x universes of ArtNet/sACN
- 4 Analog outputs
- On-board Dual Ethernet
- High power MOSFET Transistors
- Mounts in 1/2 rack space
- Class-D amplifiers (up to 75W)
- Dual Mic input and line input
- 2 effects channels (non-polyphony)
- Integrated DMX/ArtNet/sACN merger
- Integrated SD/SLC storage
- CANopen Master
- Optical audio output
- Balanced audio output (HX/VX only)
Flexible Integration
ProCommander® Series
Show Playback Devices
ProCommander® Series
The ProCommander® Series features solid-state show controllers built for playback of synchronous audio, video, animation, lighting, and mechanical action. The controllers’ flexible architecture options and open control protocols allow inspired attractions to be designed without hardware limitations.
Designed for daily operation in harsh environments, ProCommanders are built to run 24 hours a day, 7 days a week. Shows can be set to loop on power-up; be triggered internally by other timelines, digital or analog inputs; wait to sync with incoming SMPTE timecode; or simply begin from a UDP command via a touchscreen or theater automation system.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
- 5 models to choose from
- PNP, NPN, Relay output options
- 4 Universes of DMX (via Pro I/O™)
- 1 Universe of internal DMX/ArtNet
- MP3, AAC, OGG audio playback
- Built in playback storage (MicroSD/SD)
- Network enabled
- Up to 16 channels of audio output
- High frame rate and resolution
- Up to 32 Pro I/O add-on modules
- High amperage Mosfet output
- Cross platform software
-
-
-
-
-
-
-
-
-
-
-
-
-
- 5 models to choose from
- PNP, NPN, Relay output options
- 4 Universes of DMX (via Pro I/O™)
- 1 Universe of internal DMX/ArtNet
- MP3, AAC, OGG audio playback
- Built in playback storage (MicroSD/SD)
- Network enabled
- Up to 16 channels of audio output
- High frame rate and resolution
- Up to 32 Pro I/O add-on modules
- High amperage Mosfet output
- Cross platform software
Pro I/O™ & WEMLink Series
Network Distributed Expansion
Pro I/O™ Interfaces
Pro I/O Interfaces are network devices for controlling and interfacing with many types of external equipment. Pro I/O’s are extremely flexible in handling different input signals and in processing to device-specific outputs. They support a variety of industry standard lighting and industrial show control protocols, enabling control of animatronics, mechanical action equipment, remote lighting and environmental lighting controls within the same show control environment.
Using standard networking or local powered daisy chain connections, up to 32 Pro I/O devices can be connected to a single ProCommander™ for easy expansion. Choose from digital, analog, serial and lighting protocols. Connecting to an existing PLC system? Digital Motor? WEMLink and Weigl’s Digital Motor program can facilitate connection as a CANOpen Master, EtherCAT slave and more.
-
-
-
-
- 9 models to choose from
- WEMNet powered daisy chain
- Network enabled
- ArtNet enabled
- DMX Read-In/Merge
- Digital Motor Support (Servo/CAN)
- Up to 32 modules per ProCommander®
- Supports X-Series, ProCommander® Series and Pro VP™
- 12-24vdc input
- NPN, PNP Relay options
- RS-485
- RS-232
- 19″ Rack mount and DIN-Rail adapter available
- Cross platform software
-
-
-
Complementary to the Pro I/O™ series, WEMLink allows next generation third-party integration to our award winning motion and interactive control architectures, while allowing seamless communication to industrial motion control architectures. Using standard networking or local WEM-Net connections, the WEMLink modules can provide easy, full resolution, low latency motion control expansion to PLCs without additional setup. Analog channels within Weigl pass through easily to PLC applications and hardware.
Contact us for additional information regarding this product: Email Us
- 100 channels of streaming motion data via native EtherCAT
- 100 variables can be routed to any ProCommander®
- Full Weigl logic integration
- Use familiar Weigl timeline software
- Minimum 100fps resolution (Showforge™/ ConductorPro)
- Extremely low latency (~1ms at 100fps – application dependent)
- Custom applications available, contact us for additional information
- Works with any ProCommander® device
- Works direct with ConductorPro / Showforge™
PrismTag™ & Score Master Systems
Scoring & Targeting
CAT-6 Daisy Chain Connection
Weigl Prismtag™ targets are powered and controlled through a unique daisy chain CAT6A arrangement using standard cables.
Full 7 RGB Programable LED Ring
4x Fully Programmable Digital Outputs
4x Digital outputs provide local prop and effects triggers nearby to your target locations.
Enterprise Class Expansion
Video Playback Hardware
Advanced search and sync
Frame Synced Seamless Playback
These video players can certainly stand-alone, however, many of the features developed for them, were born from our animation and motion control core. Seamless playback with timecode synchronization via industry standards such as MTC and Art-Net timecode, combined with frame locked dual channel playback easily possible for applications such as character eyes and motion control centered applications.
Load your videos via USB or through our intuitive web-based configuration controls. Once onboard, trigger videos through RS-232, UDP and beyond. When combined with Showforge, workflow parameters become even more integrated and automated. Built for professional applications, this player can be linked to other VP’s, any of our ProCommander® devices and more.
Expand With Full Control
Need more control beyond just playback, synced and seamless trigger? The ProCommander® VX embeds the Pro™VP with an expanded version of our core X-Series devices, such as the ProCommander® AX. With an additional 4 channels of uncompressed audio with polyphony, 16 universes of lighting control and an ultra powerful Class-D amplifier, the VX currently can run fully interactive exhibits or attractions from a single rack space.
Load your videos via USB or through our intuitive web-based configuration controls. Once onboard, trigger videos through RS-232, UDP, or employ any of the standard triggering methods for Weigl ProCommander® devices. From 0-10vdc analog to DMX/ArtNet/sACN value shifts, combined with frame-locked synchronization, your interactive possibilities are endless.
- 2x 1080p outputs (frame locked)
- 1x 4k output for high resolution content
- Frame search
- Network timecode synchronization via ArtNet or MTC code
- SMPTE timecode input for complete show sync
- 36 GB onboard storage standard
- 16 digital inputs
- 16 digital outputs
- 8 Analog inputs
- 4 Analog outputs with optional feedback
- CANOpen
- 16 Universes of lighting control (via sACN/ArtNet)
